Rolling Counter Doors - 650 Model 650

Rolling Counter Doors - 650 Model 650

​​​​​​​​​​​​​​​​​​​​​​​​​​Distinguished by their painted galvanized steel slat curtain finish, Model 650 rolling counter doors are designed to fit openings to 20' wide and 9' high. These doors are ideal for a host of small-opening applications where security is important and a non-rated door is appropriate. Common applications include concession areas, cafeterias, pharmacies, parts-storage areas and ticket windows.​​​​



Standard Max Width20' (6096 mm)
Standard Max Height9'0" (2743 mm)
CurtainInterlocking flat profile slats (F-158) with endlocks; galvanized steel
HoodGalvanized steel
FinishGalvanized steel primed with choice of baked-on polyester top coat in gray or tan
BracketsSteel plate to support curtain, counterbalance and hood
GuidesExtruded aluminum
CounterbalanceHelical torsion springs housed in a steel tube or pipe barrel
MountingFace of wall, between jambs
OperationManual push up
LockInterior slide bolt
Warranty24 - month limited
  • Crank or electric operation
  • PowderGuard® Premium powder coat finish options are available in approximately 200 colors as well as custom matching to specification.
  • PowderGuard® Zinc and PowderGuard® Weathered finishes
  • Vision lites
  • Perforated slats
  • Fenestrated slats with uniformly spaced openings of 5/8" x 3" (16 mm x 76 mm)
  • Guides: 11-gauge roll-formed steel guides
  • Cylinder lock ​​




Commercial Standard Exterior

  • gray color swatch

    Gray

  • tan color swatch

    Tan

Powder Coat Color Options

PowderGuard® Premium powder coat options are available in approximately 200 colors as well as custom matching to specification.

Powder Guard Coat Colors

Counter Doors

Standard Exterior Color




Actual door color may vary from the digital representation shown here. Actual color samples are available by request through your Overhead Door™ Distributor.
