Fire-Rated Counter Doors with Stainless Steel Curtain, Frame and Hood​

The Model 660 integral frame fire-rated counter doors provide a handsome finished appearance for a variety of applications, including food service counters, schools, concessions, hospitals, cafeterias and retail settings. These doors are available for openings up to 9'5” x 4'5” (2870 mm x 1346 mm) and carry a UL 1-1/2 hour label for masonry and non-masonry fire walls. The 660 Series integral frame doors are factory assembled as a complete unit with fully welded frames. The curtain, frame, guides, sill, hood and bottom bar are stainless steel.

Additional safety and protection features are available, including: Fire Sentinel® time-delay release device, smoke detectors, horns, and strobes.​


Product Specifications
Standard Max Width 9'5" (2870 mm)
Standard Max Height 4'5" (1346 mm)
Labels UL 1-1/2 hour Class B for masonry and non-masonry fire walls
Operation Manual Push-up
Curtain Interlocking 22-gauge stainless steel slats
Integral frame and guides No. 4 finish stainless steel
Bottom bar To match curtain material
Sill 14 gauge stainless steel still completely enclosed with fireproof acoustic filler
​Hood No. 4 finish stainless steel
​Mounting Between jambs​
NFPA-80 compliant


  • OEM limited

Exterior Color Options:

​​Only available with Stainless Steel #4 brush finish.​ ​​​​​​​

Door Options

  • Fire Sentinel® time-delay release device/li>
  • UL listed brush-type smoke seal/li>
  • Smoke detectors/li>
  • Locking mechanisms: cylinder locking bottom bar with mortise cylinder/li>
  • Horns and horns with strobes​​
