Side Folding Full Enclosure Security Grilles 678 Model 678
Side Folding Full Enclosure Security Grilles 678 Model 678
Side Folding Full Enclosure Security Grilles Model 678 features tempered glass for a crystal-clear view and high durability. Visibility: 100% of 5-3/8" (137 mm) viewable area.
Ideal Applications Include
Construction
| Product Specifications | |
|---|---|
| Operation | Manual |
| Curtain Frame | Truss-like aluminum top and bottom plates; 1/8” (3 mm) thick |
| Panel Width | 7” (178 mm) standard body; 4” (102 mm) slim body |
| Finish | Aluminum clear anodized |
| Trolley assembly | 1 1/8” (29 mm); vertical adjustment 1" (25 mm) up/down without curtain removal |
| Track detail | Top-mounted, heavy-duty aluminum sections Height: 1 5/8" (41 mm) Width: 1 3/8" (35 mm) |
| Track Curves and Radius | 90°: Standard body: 14” (356 mm) radius; Slim body: 10” (254 mm) radius 120°, 135° and 150°; Standard and Slim body: 10” (254 mm) radius |
| Post types | Lead post Hook lock and wall channel; bi-part; top and bottom shoot bolts Intermediate post Bottom shoot bolt Trailing end post Traveling; fixed; hook lock and wall jamb; top and bottom shoot bolts; carrier |
| Locking mechanisms | Lead post Concealed cylinder-operated hook lock accessible from interior and exterior Intermediate post Concealed cylinder-operated shoot bolt accessible from one side only Trailing end post Attached 10’ max. (3048 mm) protection plate self-locking into a steel V-Stop |
Warranty
- 24 month OEM limited
Door Options
- Custom radii and curves
- Emergency Egress Door
Model 678
Standard Body
Curtain: 7” (178 mm) standard width, 1/8” (3 mm) thick tempered glass that fit into aluminum hinges. Panels are framed by min. 4” (102 mm) high aluminum bottom plates and top plates.
Visibility: 100% of 5 3/8” (137 mm) viewable area*
Model 678
Slim Body
Curtain:11 1/4” (286 mm) wide body panels, with 1/8” (3 mm) thick tempered glass that fit into aluminum hinges and are framed by min. 4” (102 mm) high aluminum bottom plates and 5 1/4” (133 mm) high aluminum top plates.
Visibility: 100% of 8 7/8” (225 mm) viewable area*
* 1” Plate separator panels on full height closures over 6’ in height
