Wireless Keypad Programming Instructions

Keypad Programming

Keypad Model OWK-BX and Model OKP-BX

Just like our garage doors and openers, our support is the best in the business. Some say that our support puts the “genuine” in our motto, “The Genuine. The Original.” because we truly care about our customers and do what i​t takes to make sure you are satisfied with your Overhead Door™ products. View the wireless programming instructions by selecting your model. Should you need additional information about installing or programming your garage door opener or remote, contact your local distributor or call customer service at 1 (877) 489-7043.

Wireless Keypad (Model OKP-BX) with CodeDodger®

Program Keypad for One Garage Door (CodeDodger® 2)

Create Your Wireless Keypad PIN (Personal Identification Number)

On your wireless keypad:

  • Press in order 3, 5, 7
  • Press the PROGRAM key
  • Enter your PIN (3 to 8 characters)
  • Press the PROGRAM key again.
  • Close the keypad cover and wait 30 seconds



Program the Keypad for a Single Door

On the power head:

  • Press and hold the PROGRAM button until both LED lights turn BLUE
  • Release button. Only the round LED will remain BLUE.
  • Press and hold the PROGRAM button again then release. The Long LED will blink PURPLE
  • Enter your PIN using the keys on the keypad
  • Press the UP/DOWN button. LEDs will stay solid.
  • Press the UP/DOWN button again. LEDs will turn off.
  • Press any key to stop the opener. (It will automatically stop at the fully open or fully closed position.)
  • The keypad backlight will turn off in approximately 30 seconds.



NOTE: If the door does not move, check the LED on the keypad. If the LED is blinking rapidly, the PIN was entered incorrectly. After the LED stops blinking, re-enter your PIN and try again. Any keypad button will control the door for 30 seconds after the door starts moving. Rapid blinking of the red LED indicates an error. After a few seconds, the LED will turn off. Start over.

Proceed to the Mounting Instructions.

Program Keypad for Multiple Garage Doors (CodeDodger® 2)

Create Your Wireless Keypad PIN (Personal Identification Number)

  • Press in order 3, 5, 7
  • Press the PROGRAM key
  • Enter your PIN (3 to 8 characters)
  • Press the PROGRAM key again.
  • Close the keypad cover and wait 30 seconds



Program the Keypad for Multiple Doors

All garage door openers will use the same PIN.

On the wireless keypad:

  • Enter your PIN and press the PROGRAM button.
  • Press the PROGRAM button again.
  • Press the number of doors you wish to control (2 or 3)
  • Press the program button again.



On your garage door opener power head:

  • Select the first opener and press and hold the PROGRAM/SET button until both LED lights turn BLUE.
  • Release the button. Only the round LED will be BLUE.
  • Press the UP/DOWN button again. LEDs will turn off.
  • Press any key to stop the opener. (It will automatically stop at the fully open or fully closed position.)
  • The keypad backlight will turn off in approximately 30 seconds.



NOTE: If the door does not move, check the LED on the keypad. If the LED is blinking rapidly, the PIN was entered incorrectly. After the LED stops blinking, re-enter your PIN and try again. Any keypad button will control the door for 30 seconds after the door starts moving. Rapid blinking of the red LED indicates an error. After a few seconds, the LED will turn off. Start over.

Proceed to the Mounting Instructions

Mounting Instructions

The keypad must be mounted in sight of the door(s), at least 5 feet above the ground and clear of any moving door parts. Mounting screws are located inside the battery compartment.

  • Remove the battery cover and batteries
  • Drill a 1/16" pilot hold for the tip mounting screw.
  • Install a screw into the drilled hole, leaving a 1/8" gap between the screw head and the wall.
  • Hook the keypad over the screw.
  • Mark and drill the pilot hole and fasten the bottom screw.
  • Install batteries and cover.



Additional Instructions

Change Your PIN

  • Enter your current PIN and press the PROGRAM button
  • Enter your NEW PIN and press the PROGRAM button.



Using A Temporary PIN

A temporary PIN allows temporary access to your home by repair persons, meter readers, etc.

  • Enter your current PIN and press the PROGRAM button 3 times.
  • Enter your temporary PIN and press the PROGRAM button.

NOTE: Do NOT reprogram the garage door opener(s). A temporary PIN remains active only until the next time your normal PIN is entered.



Forgot Your PIN (Resetting Wireless Keypad)

  • Press and hold the PROGRAM button
  • While holding the PROGRAM button, press and hold the UP/DOWN button for 5 seconds.
  • Release both buttons. You must now start from the beginning and reprogram your wireless keypad.



Changing Battery

  • If the keypad backlight does not come on, this indicates the need to replace the batteries.
  • Press in on the front of the battery cover and slide it down off of the keypad.
  • Remove used batteries and replace them with "AAA" batteries.
  • No programming is lost during the replacement of batteries.​​​​​​​​​​​​​​

Wireless Keypad (Model OWK-BX) Instructions



Testing Garage Door Opener

Create Your Wireless Keypad PIN (Personal Identification Number)

  • Enter your personal identification number (PIN).
  • Press the button with the arrow up/down triangles.



Resetting/Clearing Keypad

  • Press and hold the PROG button. Keep holding and proceed to step two.
  • Press and hold the 6 button. Keep holding and proceed to step three.
  • Press the key with the arrow up/down triangles.



Setting PIN On Keypad

  • Press the following keys in order: 3, 5, 7, PROG (red LED blinks once per second).
  • Enter your PIN (three to eight characters).
  • Press the PROG key again (the red LED blinks twice per second and turns off).

Getting Started

Before you begin, be aware of the following: For convenience, program your keypad before mounting.If programming your garage door opener is disrupted at any point due to program failure, clear/reset your keypad. Then, start over. Locate the “Learn Code” button and the “Learn Code” red LED indicator.

Programming One Garage Door Opener

  • Press the “Learn Code” button once (red LED indicator will blink).
  • Enter your PIN.
  • Press the button with the arrow up/down triangles. The “Learn Code” indicator LED will stay on.
  • Press the button with the arrow up/down triangles a second time. The “Learn Code” indicator LED will turn off.
  • Press the button with the arrow up/down triangles a third time. Garage door should now move.



Programming Two Or Three Garage Door Openers

  • All garage door openers will use the same PIN.



Programming The Wireless Keypad

  • Enter your PIN and press the PROG button (red LED blinks once per second).
  • Press the PROG button a second time (red LED blinks twice per second).
  • Press the total number of doors you wish to control (either 2 or 3).
  • Press the PROG button a third time (the red LED blinks several times and turns off).



Programming Garage Door Opener

  • Decide which door will be Door 1, 2 and 3. “Learn Code” indicator LED (on opener) blinks.
  • Enter your PIN and press the arrow up/down triangle button. “Learn Code” indicator LED continues to blink.
  • Press the number you have picked for this door opener: 1, 2 or 3. “Learn Code” indicator LED stays on.
  • Press the arrow up/down triangle button a second time. “Learn Code” indicator LED turns off.
  • Press the arrow up/down triangle button a third time. The garage door should move.



Repeat steps one through five to program each garage door opener. Each door opener must be programmed to receive the signal from the wireless keypad.
